• Pickup bed includes bed assist step (Deleted when (ZW9) pickup bed delete is ordered.)
• Air filter, heavy-duty
• Air filtration monitoring
• Transfer case, two-speed electronic shift with push button controls (Requires 4WD models.)
• Auto-locking rear differential
• Four wheel drive
• Recovery hooks, front, frame-mounted, Black
• Frame, fully-boxed, hydroformed front section and a fully-boxed stamped rear section
• Suspension Package (Not available with (X31) Off-Road Package.)
• Steering, Recirculating Ball with smart flow power steering system
• Brakes, 4-wheel antilock, 4-wheel disc with DURALIFE rotors
• Brake lining wear indicator

• Wheels, 18" (45.7 cm) 8-spoke painted steel, Silver Extended (Requires single rear wheels.)
• Tires, LT275/70R18E all-terrain, blackwall (Requires single rear wheels.)
• Tire, spare LT275/70R18 all-terrain, blackwall (Included and only available with (QF6) LT275/70R18E all-terrain, blackwall tires with (E63) pickup bed single rear wheel models. Available to order when (ZW9) pickup bed delete and (QF6) LT275/70R18E all-terrain, blackwall tires are ordered with single rear wheel models.)
• Single Rear Wheels
• Tire carrier lock keyed cylinder lock that utilizes same key as ignition and door (Deleted with (ZW9) pickup bed delete.)
• Bumper, front chrome lower
• Bumper, rear chrome with bumper CornerSteps
• CornerStep, rear bumper
• Bed Step, Black integrated on forward portion of bed on driver and passenger side (Not available with (ZW9) pickup bed delete.)
• Moldings, beltline, Black
• Cargo tie downs (12), fixed, rated at 500 lbs per corner
• Grille, Chrome surround with Black mesh
• Headlamps, LED reflector with incandescent turn signals and LED signature Daytime Running Lamps
• Taillamps, LED tail and SRW are incandescent stop, turn and reverse light and DRW are LED stop, turn and reverse light
• Lamps, cargo area, cab mounted integrated with center high mount stop lamp, with switch in bank on left side of steering wheel
• Mirrors, outside high-visibility vertical trailering lower convex mirrors, manual-folding/extending (extends 3.31" [84.25mm]), molded in Black
• Glass, solar absorbing, tinted
• Door handles, Black grained
• Tailgate, standard (Deleted with (ZW9) pickup bed delete.)
• Tailgate and bed rail protection caps, top (Deleted with (ZW9) pickup bed delete.)
• Tailgate, locking, utilizes same key as ignition and door (Included and only available with (QK1) standard tailgate. Deleted with (ZW9) pickup bed delete.)
• Tailgate, gate function manual, no lift assist (Deleted with (ZW9) pickup bed delete.)

• Audio system, GMC Infotainment System with 7" diagonal color touchscreen, AM/FM stereo with seek-and-scan and digital clock, includes Bluetooth® streaming audio for music and select phones; featuring wired Android Auto and Apple CarPlay capability for compatible phones
• Audio system feature, 6-speaker system (Requires Crew Cab or Double Cab model.)
• Bluetooth® for phone connectivity to vehicle infotainment system

• Seats, front 40/20/40 split-bench with upper covered armrest storage with fixed lumbar
• Seat trim, Vinyl
• Seat adjuster, driver 4-way manual
• Seat adjuster, passenger 4-way manual
• Seat, rear 60/40 folding bench (folds up), 3-passenger (includes child seat top tether anchor) (Not available with Regular Cab model.)
• Floor covering, rubberized-vinyl (Not available with LPO floor liners.)
• Steering wheel, urethane
• Steering column, Tilt-Wheel, manual with wheel locking security feature
• Driver Information Center, 3.5" diagonal monochromatic display
• Exterior Temperature Display located in radio display
• Window, power front, drivers express up/down (Standard on Crew Cab and Double Cab. On Regular Cab, included and only available with (PCI) Convenience Package.) (Standard on Crew Cab and Double Cab. On Regular Cab, included and only available with (PCI) Convenience Package or (ZLQ) Fleet Convenience Package.)
• Window, power front, passenger express down (Standard on Crew Cab and Double Cab. On Regular Cab, included and only available with (PCI) Convenience Package.) (Standard on Crew Cab and Double Cab. On Regular Cab, included and only available with (PCI) Convenience Package or (ZLQ) Fleet Convenience Package.)
• Windows, power rear, express down (Not available on Regular Cab models.)
• Door locks, power (Standard on Crew Cab and Double Cab. On Regular Cab, included and only available with (PCI) Convenience Package.) (Standard on Crew Cab and Double Cab. On Regular Cab, included and only available with (PCI) Convenience Package or (ZLQ) Fleet Convenience Package.)
• Power outlet, front auxiliary, 12-volt
• USB ports, 2 (first row) located on instrument panel
• Air conditioning, single-zone
• Air vents, rear (Not available with Regular Cab model.)
• Mirror, inside rearview, manual tilt
• Assist handles, front A-pillar mounted for driver and passenger, rear B-pillar mounted

• StabiliTrak, stability control system with Proactive Roll Avoidance and traction control includes electronic trailer sway control and hill start assist
• Daytime Running Lamps LED signature lighting
• Airbags, Dual-stage frontal airbags for driver and front outboard passenger; Seat-mounted side-impact airbags for driver and front outboard passenger; Head-curtain airbags for front and rear outboard seating positions; Includes front outboard Passenger Sensing System for frontal outboard passenger airbag (Always use seat belts and child restraints. Children are safer when properly secured in a rear seat in the appropriate child restraint. See the Owner's Manual for more information.)
• Rear Vision Camera (Deleted with (ZW9) pickup bed delete.)
• Hitch Guidance dynamic single line to aid in truck trailer alignment for hitching (Deleted with (ZW9) pickup bed delete.)
• Rear Seat Reminder (Requires Crew Cab or Double Cab model.)
• Seat Belt Adjustable Guide Loops front row only (Included and only available on Crew Cab and Double Cab models. Not available with (ZW9) pickup bed delete.)
• Teen Driver a configurable feature that lets you activate customizable vehicle settings associated with a key fob, to help encourage safe driving behavior. It can limit certain available vehicle features, and it prevents certain safety systems from being turned off. An in-vehicle report card gives you information on driving habits and helps you to continue to coach your new driver
• Tire Pressure Monitoring System with Tire Fill Alert (does not apply to spare tire)

• Trailering Information Label provides max trailer ratings for tongue weight, conventional, gooseneck and 5th wheel trailering (Not available with (ZW9) pickup bed delete.)

BED LINER, SPRAY-ON

• Pickup bedliner (does not include spray-on liner on tailgate due to Black composite inner panel)

PRO PREFERRED EQUIPMENT GROUP

• includes standard equipment

HEAVY DUTY FRONT SPRING/CAMPER PACKAGE

• Note: If ordered for Camper usage
• recommend ordering (UY2) Trailering wiring provisions

AUDIO SYSTEM, GMC INFOTAINMENT SYSTEM WITH 7" DIAGONAL COLOR TOUCHSCREEN, AM/FM STEREO

• with seek-and-scan and digital clock
• includes Bluetooth® streaming audio for music and select phones; featuring wired Android Auto and Apple CarPlay capability for compatible phones (STD)

POWER OUTLET, BED MOUNTED, 120-VOLT

• (400 watts shared with (KI4) instrument panel mounted power outlet)

DUAL REAR WHEELS

• includes LED hip marker lights

CONVENIENCE PACKAGE

• includes (AQQ) Remote Keyless Entry
• (QT5) EZ Lift power lock and release tailgate
• (AKO) tinted glass
• (UF2) LED cargo bed lighting
• (C49) rear-window defogger
• (DBG) outside power-adjustable vertical trailering with heated upper glass and (K34) cruise control

DRIVER INFORMATION CENTER, 4.2" DIAGONAL COLOR DISPLAY

• includes driver personalization

SEATS, FRONT 40/20/40 SPLIT-BENCH

• with upper covered armrest storage with fixed lumbar (STD)

PICKUP BED

• includes bed assist step (STD)

LED CARGO AREA LIGHTING

• located in cargo bed activated with switch on center switch bank or key fob

• WHEELS 17 (43.2 CM) PAINTED STEEL
• TIRES LT235/80R17E ALL-SEASON HIGHWAY BLACKWALL
• BED LINER SPRAY-ON Pickup bedliner (does not include spray-on liner on tailgate due to Black composite inner panel)
• WHEEL TRIM PAINTED CENTER CAPS
• GOOSENECK / 5TH WHEEL PREP PACKAGE -- Hitch platform to accept Gooseneck or 5th Wheel hitch. Includes hitch platform with tray to accept ball stamped bed holes with removable caps installed and bed mounted 7-pin trailer harness (similar to UY2 harness).
• LICENSE PLATE KIT FRONT
• CRUISE CONTROL STEERING WHEEL-MOUNTED
• POWER OUTLET INSTRUMENT PANEL 120-VOLT (400 watts shared with (KC9) bed mounted power outlet)
• TRANSMISSION ALLISON 10-SPEED AUTOMATIC
• ENGINE DURAMAX 6.6L TURBO-DIESEL V8 B20-DIESEL COMPATIBLE (445 hp [332 kW] @ 2800 rpm 910 lb-ft of torque [1220 Nm] @ 1600 rpm) Includes (K05) engine block heater.)
• REMOTE KEYLESS ENTRY
• PRO PREFERRED EQUIPMENT GROUP includes standard equipment
• STEERING WHEEL AUDIO CONTROLS
• HEAVY DUTY FRONT SPRING/CAMPER PACKAGE Note: If ordered for Camper usage recommend ordering (UY2) Trailering wiring provisions
• MIRRORS OUTSIDE POWER-ADJUSTABLE VERTICAL TRAILERING WITH HEATED UPPER GLASS lower convex mirrors integrated turn signals manual folding/extending (extends 3.31 [84.25mm]) Black
• DEFOGGER REAR-WINDOW ELECTRIC
• AUDIO SYSTEM GMC INFOTAINMENT SYSTEM WITH 7 DIAGONAL COLOR TOUCHSCREEN AM/FM STEREO with seek-and-scan and digital clock includes Bluetooth® streaming audio for music and select phones; featuring wired Android Auto and Apple CarPlay capability for compatible phones (STD)
• POWER OUTLET BED MOUNTED 120-VOLT (400 watts shared with (KI4) instrument panel mounted power outlet)
• WINTER GRILLE COVER
• GLASS DEEP-TINTED
• GVWR 14 000 LBS. (6350 KG) WITH DUAL REAR WHEELS
• ENGINE BLOCK HEATER
• DUAL REAR WHEELS includes LED hip marker lights
• CONVENIENCE PACKAGE includes (AQQ) Remote Keyless Entry (QT5) EZ Lift power lock and release tailgate (AKO) tinted glass (UF2) LED cargo bed lighting (C49) rear-window defogger (DBG) outside power-adjustable vertical trailering with heated upper glass and (K34) cruise control
• TRAILER BRAKE CONTROLLER INTEGRATED
• DRIVER INFORMATION CENTER 4.2 DIAGONAL COLOR DISPLAY includes driver personalization
• JET BLACK VINYL SEAT TRIM
• SEATS FRONT 40/20/40 SPLIT-BENCH with upper covered armrest storage with fixed lumbar (STD)
• TIRE SPARE LT235/80R17E HIGHWAY
• 1SA SAFETY CONFIDENCE PACKAGE includes (UEU) Forward Collision Alert (UHY) Automatic Emergency Braking (K34) Cruise Control (UK3) Steering wheel audio controls and (UDD) Driver Information Center
• LAMPS SMOKED AMBER ROOF MARKER (LED)
• REAR AXLE 3.42 RATIO
• GOOSENECK / 5TH WHEEL PACKAGE includes (Z6A) Gooseneck / 5th Wheel Prep Package. Includes (JL1) Trailer brake controller and (CGN) spray-on bed liner.
• AUTOMATIC EMERGENCY BRAKING
• EXHAUST BRAKE
• ONYX BLACK
• PICKUP BED includes bed assist step (STD)
• LED CARGO AREA LIGHTING located in cargo bed activated with switch on center switch bank or key fob
• ALTERNATOR 220 AMPS
• TAILGATE GATE FUNCTION MANUAL WITH EZ LIFT includes power lock and release includes hitch area light
• FORWARD COLLISION ALERT
• Tow Hitch
• Running Boards/Side Steps
• Locking/Limited Slip Differential
• Four Wheel Drive
• Tow Hooks
• Power Steering
• ABS
• 4-Wheel Disc Brakes
• Steel Wheels
• Tires - Front All-Terrain
• Tires - Rear All-Terrain
• Conventional Spare Tire
• Daytime Running Lights
• AM/FM Stereo
• MP3 Capability
• Bluetooth® Connection
• Auxiliary Audio Input
• Smart Device Integration
• Bluetooth® Connection
• Split Bench Seat
• Vinyl Seats
• Pass-Through Rear Seat
• Rear Bench Seat
• Floor Mats
• Adjustable Steering Wheel
• Power Windows
• Power Windows
• Power Windows
• Power Door Locks
• Power Outlet
• MP3 Capability
• Auxiliary Audio Input
• A/C
• Traction Control
• Stability Control
• Daytime Running Lights
• Driver Air Bag
• Passenger Air Bag
• Front Side Air Bag
• Front Head Air Bag
• Rear Head Air Bag
• Passenger Air Bag Sensor
• Back-Up Camera
• Driver Restriction Features
• Tire Pressure Monitor

• Electrical
• Cold Cranking Amps @ 0° F (Primary): 720
• Maximum Alternator Capacity (amps): 220
• Maximum Alternator Capacity (amps): 170
• Cooling System
• Total Cooling System Capacity (qts): - TBD -
• Weight Information
• Gross Axle Wt Rating - Front (lbs): 6000
• Gross Axle Wt Rating - Front (lbs): 5600
• Gross Axle Wt Rating - Front (lbs): 5200
• Gross Axle Wt Rating - Rear (lbs): 10500
• Gross Axle Wt Rating - Rear (lbs): 7250
• Curb Weight - Front (lbs): 4046
• Curb Weight - Rear (lbs): 3126
• Gross Vehicle Weight Rating Cap (lbs): 14000
• Gross Vehicle Weight Rating Cap (lbs): 11500
• Gross Combined Wt Rating (lbs): 40000
• Gross Combined Wt Rating (lbs): 29700
• Gross Combined Wt Rating (lbs): 24000
• Trailering
• Dead Weight Hitch - Max Trailer Wt. (lbs): 5000
• Dead Weight Hitch - Max Tongue Wt. (lbs): 500
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 20000
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 16240
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 14500
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 2000
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 1624
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 1450
• Fifth Wheel Hitch - Max Trailer Wt. (lbs): 31180
• Fifth Wheel Hitch - Max Trailer Wt. (lbs): 16120
• Fifth Wheel Hitch - Max Trailer Wt. (lbs): 21040
• Fifth Wheel Hitch - Max Trailer Wt. (lbs): 16410
• Fifth Wheel Hitch - Max Tongue Wt. (lbs): 7795
• Fifth Wheel Hitch - Max Tongue Wt. (lbs): 4030
• Fifth Wheel Hitch - Max Tongue Wt. (lbs): 5260
• Fifth Wheel Hitch - Max Tongue Wt. (lbs): 4102
• Maximum Trailering Capacity (lbs): 20000
• Suspension
• Suspension Type - Front: Short/Long Arm w/Torsion Bars
• Suspension Type - Rear: 3-Stage Multi-Leaf
• Spring Capacity - Front (lbs): - TBD -
• Spring Capacity - Rear (lbs): - TBD -
• Axle Type - Front: Independent
• Axle Type - Rear: - TBD -
• Axle Capacity - Front (lbs): - TBD -
• Axle Capacity - Rear (lbs): - TBD -
• Axle Ratio (:1) - Front: 3.42
• Axle Ratio (:1) - Front: 3.73
• Axle Ratio (:1) - Rear: 3.42
• Axle Ratio (:1) - Rear: 3.73
• Shock Absorber Diameter - Front (mm): 51
• Shock Absorber Diameter - Rear (mm): 51
• Stabilizer Bar Diameter - Front (in): 1.38
• Brakes
• Brake Type: Pwr
• Brake ABS System: 4-Wheel
• Disc - Front (Yes or ): Yes
• Disc - Rear (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 14 x 1.6
• Rear Brake Rotor Diam x Thickness (in): 14 x 1.6
• Rear Brake Rotor Diam x Thickness (in): 14.1 x 1.3
• Tires
• Front Tire Order Code: QQO
• Front Tire Order Code: QF6
• Rear Tire Order Code: QQO
• Rear Tire Order Code: QF6
• Spare Tire Order Code: ZQO
• Spare Tire Order Code: ZYG
• Front Tire Size: LT235/80R17
• Front Tire Size: LT275/70R18
• Rear Tire Size: LT235/80R17
• Rear Tire Size: LT275/70R18
• Spare Tire Size: LT235/80R17
• Spare Tire Size: LT275/70R18
• Front Tire Capacity (lbs): - TBD -
• Rear Tire Capacity (lbs): - TBD -
• Spare Tire Capacity (lbs): - TBD -
• Wheels
• Front Wheel Size (in): 17 x 6.5
• Front Wheel Size (in): 18 x 8
• Rear Wheel Size (in): 17 x 6.5
• Rear Wheel Size (in): 18 x 8
• Spare Wheel Size (in): 17 x 6.5
• Spare Wheel Size (in): 18 x 8
• Front Wheel Material: Steel
• Rear Wheel Material: Steel
• Spare Wheel Material: Steel
• Steering
• Steering Type: Pwr Recirculating Ball
• Steering Ratio (:1), On Center: - TBD -
• Steering Ratio (:1), At Lock: N/A
• Turning Diameter - Curb to Curb (ft): 57.0
• Turning Diameter - Wall to Wall (ft): N/A
• Frame
• Frame Type: Hydroformed
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 36
• Fuel Tank Location: - TBD -
• Exterior Dimensions
• Wheelbase (in): 172
• Length, Overall (in): 266.09
• Width, Max w/o mirrors (in): 96.6
• Width, Max w/o mirrors (in): 81.85
• Height, Overall (in): 80.04
• Height, Overall (in): 80.67
• Overhang, Front (in): - TBD -
• Overhang, Rear w/o bumper (in): - TBD -
• Front Bumper to Back of Cab (in): - TBD -
• Cab to Axle (in): 55.2
• Cab to End of Frame (in): - TBD -
• Ground to Top of Load Floor (in): - TBD -
• Ground to Top of Frame (in): - TBD -
• Frame Width, Rear (in): - TBD -
• Ground Clearance, Front (in): 10.39
• Ground Clearance, Front (in): 11.14
• Ground Clearance, Rear (in): 10.39
• Ground Clearance, Rear (in): 11.14
• Cargo Area Dimensions
• Cargo Box Length @ Floor (in): 98.27
• Cargo Box Width @ Top, Rear (in): - TBD -
• Cargo Box Width @ Floor (in): 71.4
• Cargo Box Width @ Wheelhousings (in): 50.55
• Cargo Box (Area) Height (in): 21
• Tailgate Width (in): - TBD -
• Cargo Volume (ft³): 83.5
• Ext'd Cab Cargo Volume (ft³): - TBD -
• Interior Dimensions
• Passenger Capacity: 6
• Front Head Room (in): 43.03
• Front Leg Room (in): 44.53
• Front Shoulder Room (in): 66.02
• Front Hip Room (in): 61.18
• Second Head Room (in): 40.12
• Second Leg Room (in): 43.4
• Second Shoulder Room (in): 65.3
• Second Hip Room (in): 60.24
• Summary
• Vehicle Name: GMC Sierra 3500HD
• Body Style: Crew Cab Pickup
• Body Code: E63
